Cantilever Arms

P2631T

P2631T

[ back to index ] [ image ]   [ data ]

Data

Load Data (All Loads are kN)
Part No.
P2631T/150 150 5.95 2.97 2.97 1.98
P2631T/300 300 3.07 1.53 1.53 1.02
P2631T/450 450 2.06 1.03 1.03 0.68
P2631T/600 600 1.56 0.78 0.78 0.52
P2631T/750 750 1.25 0.62 0.62 0.41



Part No. Finish Size Length Weight
P2631T/150 HG 21mm 150mm 1.02
P2631T/300 HG 21mm 300mm 1.55
P2631T/450 HG 21mm 450mm 2.08
P2631T/600 HG 21mm 600mm 2.61
P2631T/750 HG 21mm 750mm 3.13
P2631T/150 SS 21mm 150mm 1
P2631T/300 SS 21mm 300mm 1.53
P2631T/450 SS 21mm 450mm 2.06
P2631T/600 SS 21mm 600mm 2.59
P2631T/750 SS 21mm 750mm 3.12
