Cantilever Arms

P2633T

P2633T

[ back to index ] [ image ]   [ data ]

P2633T

Data

Load Data (All Loads are kN)
Part No.
P2633T/150 150 1.94 0.97 0.97 0.64
P2633T/300 300 1 0.5 0.5 0.33
P2633T/450 450 0.67 0.33 0.33 0.22



Part No. Finish Size Length Weight
P2633T/150 HG 21mm 150mm 0.65
P2633T/300 HG 21mm 300mm 0.91
P2633T/450 HG 21mm 450mm 1.18
P2633T/150 SS 21mm 150mm 0.63
P2633T/300 SS 21mm 300mm 0.88
P2633T/450 SS 21mm 450mm 1.15
