Cantilever Arms

P2663T

P2663T

[ back to index ] [ image ]   [ data ]

P2663T

Data

Load Data (All Loads are kN)
Part No.
P2663T/150 150 6.12 3.06 3.06 2.04
P2663T/300 300 3.06 1.53 1.53 1.02
P2663T/450 450 2.04 1.02 1.02 0.68
P2663T/600 600 1.53 0.76 0.76 0.5
P2663T/750 750 1.22 0.61 0.61 0.4



Part No. Finish Size Length Weight
P2663T/150 HG 41mm 150mm 0.8
P2663T/300 HG 41mm 300mm 1.24
P2663T/450 HG 41mm 450mm 1.65
P2663T/600 HG 41mm 600mm 1.87
P2663T/750 HG 41mm 750mm 2.47
P2663T/150 SS 41mm 150mm 0.79
P2663T/300 SS 41mm 300mm 1.2
P2663T/450 SS 41mm 450mm 1.6
P2663T/600 SS 41mm 600mm 2
P2663T/750 SS 41mm 750mm 2.4
P2663T/150 ZP 41mm 150mm 0.67
P2663T/300 ZP 41mm 300mm 1.18
P2663T/450 ZP 41mm 450mm 1.61
P2663T/600 ZP 41mm 600mm 1.75
P2663T/750 ZP 41mm 750mm 2.16
