Cantilever Arms

P2668T

P2668T

[ back to index ] [ image ]   [ data ]

P2668T

Data

Load Data (All Loads are kN)
Part No.



Part No. Finish Size Length Weight
P2668T/150 HG 41mm 150mm 0.8
P2668T/300 HG 41mm 300mm 1.17
P2668T/450 HG 41mm 450mm 1.59
P2668T/600 HG 41mm 600mm 2.03
P2668T/150 SS 41mm 150mm 0.88
P2668T/300 SS 41mm 300mm 1.28
P2668T/450 SS 41mm 450mm 1.41
P2668T/600 SS 41mm 600mm 2.08
